電氣性能

額定電壓 300V 450V
額定電流 10A 18A
導線線徑 26-14AWG 0.5-2.5mm2
耐電壓 AC2000V/1Min

機械性能
扭力矩 0.4Nm(3.5Lb-In.)
環境溫度 -40°C~+105°C
剝線長度 6-7mm

尺寸
間距 5.0mm(.197")
極數 2P,3P-24P

材質和電鍍
塑件 PA66,UL94V-0
螺絲 M2.5,鋼,鍍Cr3+鈍化彩鋅
焊針 黃銅,鍍錫
簧片 不銹鋼

Electrical performance

Rated voltage 300V 450V
Rated Current 10A 18A
Wire diameter 26-14AWG 0.5-2.5mm2
Dielectric AC2000V/1Min

Mechanical properties
Torque 0.4Nm (3.5Lb-In.)
Ambient temperature of -40 ° C ~ +105 ° C
Strip length 6-7mm

Size
Spacing 5.0mm (.197 ")
Number of poles 2P, 3P-24P

Material and plating
Plastic PA66, UL94V-0
Screw M2.5, steel, zinc plating Cr3 + passive color
Solder pin brass, tin plated
Stainle  teel reed
