FEATURES

SPECIFICATION
UDP SERIES 1500W

MODEL

UDP-3050

UDP-5003

UDP-15010

OUTPUT

30V 50A

500V 3A

150V 10A

OUTPUT

WATT

1500W

1500W

1500W

VOLTAGE(CV)

0 ~ 30V

0~500V

0~150V

CURRENT(CC)

0 ~ 50A

0~3A

0~10A

Programming Accuracy
(At 25∩±5∩)

Voltage

0.04% + 10��

0.1% + 300��

0.06% + 80��

Current

0.1% + 50��

0.1% + 3��

0.1% + 10��

RIPPLE & NOISE
(from 20Hz to 20MHz)

Voltage normal mode(rms/p-p)

5��/10��

50��/150��

15��/30��

Current

100��

6��

20��

Readback Accuracy
(At 25∩±5∩)

Voltage

0.04% + 10��

0.1% + 300��

0.06% + 80��

Current

0.1%+50��

0.1%+3��

0.1%+10��

LOAD REGULATION

Voltage

7��

100��

20��

Current

50��

3��

10��

LINE REGULATION

Voltage

7��

100��

20��

Current

5��

2��

2��

CONTROL
RESOLUTION

Voltage

1��

100��

10��

Current

10��

0.1��

1��

L.C.D DISPLAYER

VOLTAGE

2 ×16 LCD 4 ½  AUTO RANGE OF 5 READING/Sec

CURRENT

2 ×16 LCD 4 ½  AUTO RANGE OF 5 READING/Sec

PROTECTION
SETTING

OVER VOLTAGE

FULL SCALE OF DC OUTPUT VOLTAGE + 9%

OVER CURRENT

FULL SCALE OF DC OUTPUT CURRENT + 2% (ONLY O.C.P OUTPUT MODE)

TEMPERATURE

ONLY HEAT SINK 85∩

AUTO SEQUENCE
(DYNAMIC)

AUTO RUN STEP

MAXIMUM 100 STEP

SETTING TIME

1ms ~ 50,000s (Per 10Я)

SLOPE TIME

1ms ~ 50s (Per 10Я)

COUNTER

1 ~ 50,000 CYCLE ("0" SET: ★)

TRANSIENT RECOVERY TIME

100 Я  (50%LOAD CHARGE,MINIMUM LOAD 0.5A)

OPERATING ENVIRONMENT

0~50 ∩,80%R.H.

MEMORY ADDRESS

MAX. 100 POINTS (VOLTAGE, CURRENT, TIME, SLOPE)

INTERFACE FOR PC

GP-IB(OPTION), RS-232C(RS-485)

AC POWER SOURCE

AC 110/220V ± 10% , 50/60 г (CUSTOMER MADE)

ACCESSORIES

INPUT POWER CORD, MANUAL , OUTPUT CABLE, SOFTWARE(ONLY RS-232C) CD , RS-232C CABLE

WEIGHT (APPROX)

65 Kg

62 Kg

63 Kg

DIMENSION(W*H*D М)

420*200*550

420*200*550

420*200*550
